EMT

4230-1-4-FT

Product Family:
EMT
Certification:
CE
Refrigerant Type:
R1234ze
Safety Class:
A2L
Capacity Control:
Frequency controlled

Application

Nominal Heating Capacity:
1060 kW
Nominal Cooling Capacity:
932 kW
Nominal COP Heating:
4.33
Nominal COP Cooling:
4.03
Condenser Outlet Temp.:
55 °C
Evaporator Inlet Temp.:
-5 °C
Lowest Evaporator Temp. To Reach Highest Condenser Temp.:
7 °C
Highest Evaporator Outlet Temp.:
25 °C

Dimensions

Length:
N/A
Width:
N/A
Height:
N/A
Weight:
N/A

Technical Features

Compressor Type:
Turbo
Energy Source:
Ground, Waste heat, Water
Special Features:
Economizer, Oil-free
GWP:
1.37

This Energy Machines™ model contains four oil-free centrifugal compressors in one refrigerant circuit. The compressors are classified as nonpositive displacement compressors.

This model is equipped with a flash tank, increasing its energy efficiency. The machine’s evaporator and condenser are shell-and-tube heat exchangers. The evaporator operates with a flooded evaporation technique.

These components work together to create a powerful and efficient machine.
